The Erba EC-90 Electrolyte Analyzer is a compact, high-performance diagnostic instrument designed to measure critical electrolytes like sodium (Na⁺), potassium (K⁺), chloride (Cl⁻), calcium (Ca²⁺), and lithium (Li⁺) in biological fluids with precision and speed. Widely used in clinical laboratories, hospitals, and point-of-care settings, this analyzer combines advanced ion-selective electrode (ISE) technology with user-friendly features to deliver reliable results within seconds.

With growing demand for quick and accurate diagnostics, the EC 90 helps healthcare professionals make informed decisions promptly, improving patient outcomes. Its ease of use, low maintenance requirements, and high-throughput capabilities make it a go-to electrolyte analyzer for busy medical environments.

---

EC-90 Electrolyte Analyzer Key Features:

• Ion-selective electrode (ISE) technology

• Fast analysis time: Results in less than 60 seconds

• Simultaneous measurement of multiple parameters

• Touchscreen interface for easy operation

• Compact & lightweight design

• Low sample volume requirement

• Built-in printer for instant result output

• Auto calibration & quality control functions

---

EC-90 Electrolyte Analyzer Advanced ISE Technology

At the core of the EC 90’s precision lies ion-selective electrode technology, which ensures highly accurate measurements of key electrolytes from serum, plasma, whole blood, or urine. This method offers direct, reliable readings, minimizing the risk of analytical error often seen in indirect measurement systems.

Whether used in emergency diagnostics, routine check-ups, or intensive care units, the analyzer provides consistent and reproducible results, which are critical for monitoring electrolyte imbalances, dehydration, renal conditions, and other systemic disorders.

---

EC-90 Electrolyte Analyzer User-Friendly Interface

The Erba EC 90 is designed with an intuitive touchscreen display that simplifies daily operation for lab technicians. The menu-driven interface guides users through each step of the testing process, from sample loading to result printing. Even users with minimal training can efficiently operate the analyzer with confidence.

Additionally, the system offers automatic calibration and built-in quality control checks to ensure every test meets clinical accuracy standards. Alerts notify users when calibration is required, or results fall outside of the acceptable range.

---

EC-90 Electrolyte Analyzer High-Speed Analysis

Time is critical in clinical decision-making, and the EC 90 delivers test results in under one minute. With its rapid turnaround time, this electrolyte analyzer supports high patient throughput, which is especially beneficial in emergency rooms and ICUs.

Requiring only 100–150 µL of sample volume, the analyzer is ideal for pediatric, geriatric, or critical patients where blood draw volume is limited. This small sample requirement also helps reduce patient discomfort and blood wastage.

---

EC-90 Electrolyte Analyzer Compact Design

With its space-saving design, the EC 90 fits easily into small laboratory benches or bedside setups. Despite its compact size, it delivers robust functionality, performing multiple electrolyte tests in one run. The built-in thermal printer instantly generates easy-to-read reports, eliminating the need for external equipment or manual documentation.

Moreover, the analyzer supports both open and closed sampling systems, giving labs the flexibility to operate based on their specific workflow requirements.

---

Maintenance and Cost Efficiency

The Erba EC 90 stands out not only for its performance but also for its low maintenance and operational costs. Designed with easy-to-clean components and long-lasting electrodes, the analyzer ensures maximum uptime and minimal service interruptions.

Consumables such as reagents and calibrators are economically priced and easy to replace. Auto-cleaning features help maintain electrode integrity and prevent clogging or contamination between runs.

---

Applications in Modern Healthcare

The EC 90 is suitable for a wide range of medical settings, including:

• Hospital laboratories

• Emergency and critical care units

• Dialysis and nephrology centers

• Pediatric and geriatric clinics

• Diagnostic labs and research facilities

Accurate electrolyte monitoring is crucial in diagnosing conditions such as:

• Dehydration and fluid imbalance

• Kidney dysfunction

• Cardiac conditions

• Acid-base disorders

• Electrolyte depletion from medication or illness

---

Technical Specifications:

• Measurement Method: Ion-selective electrode (ISE)

• Parameters: Na⁺, K⁺, Cl⁻, Ca²⁺, Li⁺

• Sample Type: Whole blood, serum, plasma, urine

• Sample Volume: 100–150 µL

• Time per Test: <60 seconds

• Display: LCD touchscreen

• Printer: Built-in thermal printer

• Calibration: Auto/On-demand

• Dimensions: Approx. 330 × 300 × 130 mm

• Weight: Approx. 5 kg

---

Why Choose the Erba EC 90?

The Erba EC 90 Electrolyte Analyzer brings together speed, accuracy, and ease of use in a compact form. Designed for today’s fast-paced healthcare environment, it delivers quick, lab-quality results to support critical decision-making in patient care.

Whether you’re setting up a new diagnostic center or upgrading your lab equipment, the EC 90 is a cost-effective, high-performance solution that meets global standards of clinical testing.

Erba EC 90 – Empowering smarter diagnostics, one drop at a time.
