Full-Digital Laptop Ultrasound Scanner N50 15 Inch LCD Screen
N50 Full-digital Laptop Ultrasound Scanner Flexible and convenient operating system. A type of high array, high definition, multi-function full-digital laptop ultrasonic diagnostic apparatus. Light and portable, more clearer, delicate and smooth image, convenient to operate, and powerful electrical power ability supports the machine for consultation in various environment of cities, towns, outdoor.
★ 15 inches LCD display zone for large image size, with high quality.
★ Probe Interface Dual probe interface, with automatic identification function
★ ARM platform, fast computing, HD imaging
★ Battery Capacity: Independent battery compartment /removable lithium battery /5200 mAh
★ Four encoders, knob design, quick and convenient operation
★ Support multi-language switching
★ Movie playback: 256 frames, can be played back frame by frame and pause playback,
pause playback can be used for image preservation and measurement
★ Measurement: Professional measurement software;
★ Host size: 360mm(L)*355mm(W)*65mm(H)
Abdomen, Obstetrics and Gynecology, Pediatrics, Urology, Small Organs, Musculoskeletal and so on. Widely used in expert visits, community service visits，120 emergency center, Large-scale medical examination car, Severe patient, bedside examination of VIP wards etc.
✱ Convex probe
✱ Micro-convex probe
✱ Linear probe
✱ Trans-rectal probe
✱ Trans-vaginal probe
Samples
2.Display mode: B, B + B, 4b, B + m, m;
3.Four encoders, knob design, quick and convenient operation
4.Simple operation interface, easy to understand, ready to use
5.Electron focusing: four stage electron focusing;
5.There were more than 18 body position markers;
6.Frequency conversion: All probes support five-stage frequency conversion;
7.Image mirror: upper and lower mirror, left and right mirror, black and white flip;
8.Measurement: Professional software measurement package;
9.Character display: date, clock, name, gender, age, doctor, hospital, comment (full-screen character editing);
10.Gain range: 0-135db;
11.Interface: video interface, two USB interface, DICOM interface, VGA interface, power interface
12.Permanent storage: 16G built-in storage, can also be connected to external U disk storage
13.Grey scale: level 256
14.Dynamic range: 0-135db;
15.After the process: 8 kinds of Y correction, line correlation, 16 level frame correlation, point and line correlation, linear interpolation, digital spatio-temporal filtering, digital edge enhancement, 8 kinds of false color processing, etc
16.Blind area: ≤4
17.Maximum display depth :300mm
18.Geometric accuracy: transverse ≤5%, longitudinal ≤5%
19.Resolution: lateral ≤2mm, axial ≤1mm
20.Display magnification: 16 display modes; Lesion diagnosis is more accurate.
